BERGES KRM Pulley/Belt Drives
Symmetrical Pulleys for standard 10, 13, and 17mm V-belts. Pulleys for Z, 4L, A, 5L, B, US standard sizes KR Adjusting Variable Pulley on driving shaft. KM Tensioning Pulley on driven shaft. Constant distance between shafts & Constant Tension. Wide Speed Range - 6~1 variable. Suitable for Forward & Reversing operation. Power range from 1/2hp (.37kw) to 1.5hp (kw).

Model	D	L	Belts	Pitch	d* H7	Range	Motor Rpm	Kw Input	HP Input	Max Rpm OUT	Min RPM OUT
KR 80.10	80	60	10mm, Z	28o	11, 14	6 ~ 1	1644	0.25	0.33	3936	656
KM 80.10
KR 105.13	105	80	13mm, A, 4L	28o	11, 14, 19	6 ~ 1	1644	0.55	0.75	3936	656
KM 105.13
KR 127.17	127	80	17mm, B, 5L	28o	14, 19, 24	6 ~ 1	1644	0.75	1.00	4176	696
KM 127.17

* Standard bores, inch and other bores are available by request.

Berges KRM type double pulley & belt drive system is for lighter hp applications where a standard V-belt can be used.  The Adjusting pulley is the KR and the Spring Tensioning pulley is the KM; together being KRM.  These are designed to work with the standard narrow metric V-belts in the 10, 13, and 17mm widths.  The same time proven design as the RF..b is employed, but for narrower belts and lower power. The power range is in the very popular 1/2hp to 1.5hp range, with a 6/1 variable ratio, and speeds around 670 to 4000 RPM.  Ideal for a wide variety of applications where reliable variable speed is desired, and cost effective ratio control for applications from wood working tools to pumps; great variety of drive applications is driven by  the KRM. TVT America's Engineering & Sales team is here to assist you with all of your Berges Variable Pitch Pulley & Belt questions, sales, and engineering inquiries.

CLICK CATALOG SECTION FOR PDF	BERGES KRM Documentation
>          >          >          >          >        >        >        >        >      >      >      >      >      >      >   >   >   >   >   >   >   >   >   > > > > > > > > > > > >>>>>>> > > > > > > >   >   >   >   >   >   >   >      >      >      >      >        >        >        >        >        >          >          >          >          >               >               >               >                    >	Ratings & Dimensions Berges.KRM Pulleys >
SERVICE LINKS	Genuine Berges Belts for KRM >
E-MAIL TVT Engineering



Berges Antriebstechnik GmbH & Co. KG. are the manufacturers in Germany of TVT America's KRM series adjustable pitch V-belt drive pulleys for use with standard Z, A, B, C Belts, 3L, 4L, 5L Belts, as well as 10, 13, and 17mm metric V-belts. Adjustable pitch pulleys for standard V-belts Z, A, B widths allows simple, relable, globally specified Berges pulleys to be employeed for a wide 6/1 speed variation with powers to 1.5kw 2hp all with the convenience of using readily available standard Z, A, B belts, as well as ligher duty 3l, 4L, 5L belts, and even Metric 10, 13, and 17mm stanard 28 degree pitch V-Belts.   TVT America has an industrial distributor near you, as we have over 2500 distributors in Canada, USA, Mexico, Puerto Rico, Caribbean Islands, and Costa Rica.  Just ask us for assistance and we can help you design or repair the V-belt variable speed drive of your dreams. Simple to use, easy to maintain, affordable power transmission solutions.
