BERGES RF..b Pulley/Belt Drives
  • Symmetrical Pulleys for wide V-Belts
  • R..b Adjusting Variable Pulley on driving shaft.
  • F..b Tensioning Pulley on driven shaft*
  • Constant distance between shafts & Constant Tension.
  • Wide Speed Range - to 10.5~1 variable.
  • Suitable for Forward & Reversing operations.
  • Power range from 1/2hp (0.37kw) to 225hp (160kw).


TVT America offers the full range of genuine Berges Variable Speed Belt Drives made in Germany.  For replacement pulleys and belts, It is helpful to remember that the "F" type is the Spring-Tension Pulley and the "R" type is the Adjusting Pulley.  In example, to replace the Spring pulley from an RF150b-24 set, the part required is the F150b-24 pulley.  If a belt is required, the RF150b-24 set would require a 28x8 belt.. the length is determined by the outside face diameter.  For example, a 28x8x1000LI for the RF150b set, would have a 1000mm face diameter.   Contact TVT America's sales & engineering team to assist you with all your Berges Variable Pitch Pulley & Belt questions and concerns.

Click Catalog Selection for PDF

   Berges RF..b Documentation
>          >          >          >          >        >        >        >        >      >      >      >      >      >      >   >   >   >   >   >   >   >   >   > > > > > > > > > > > >>>>>>> > > > > > > >   >   >   >   >   >   >   >      >      >      >      >        >        >        >        >        >          >          >          >          >               >               >               >                    >   CUT SHEET Ratings & Dimensions Berges.RF..b Pulleys > .



   Genuine Berges Belts for RF..b > .



   RF..b Sizes > nmn,mn,n,mn,mn,mn,mn,mn,mn
